Single-Stage Compressors
J-Series
SCV-Series
UD-Series
- Newly designed, high performance, single-stage series. 9 models.
- Low vibration and low noise
- Stepless capacity control from 100&-25%
UD-Series
SCV-Series
UD-Series
- Covers wide capacity range
- Displacement of up to 15600m/h at 2950rpm, at 3550 rpm
- 4:6 rotor configuration
SCV-Series
SCV-Series
SCV-Series
- 13 models available, displacement range from 415-4740m/h (244-2790CFM) at 2950rpm, at 3550 rpm
- High performance, long selling series
- Operates over a wide range of temperatures
I-Series
SCV-Series
SCV-Series
- Small compressor, high reliability
- New design eliminates need of an oil pump
- Designed to facilitate the replacement of consumables
- Using a flange motor, the small-footprint compressor can be installed in a confined space.
- Available in 5 models
Two-Stage Compressor
C-Series
- Available in 5 models, single machine two-stage compressor to efficiently cover low temperature range
- Displacement range 622-9700m/h (441-5709CFM) at 2950rpm, at 3550rpm.
- 4:6 rotor configuration
- Operational with one motor and oil separator based on a MYCOM original design
